ESP Application Notes

The following application notes have been designed to give technical guidance in the safe application of Furse
electronic system protectors.

Application Note AN001

Protection for Resistance Temperature Detectors (RTDs), for ESP 06D, ESP SL06, ESP 06Q, ESP RTD, ESP SLRTD, ESP RTDQ

Application Note AN003

Protection for OEM data communications, signal and telephone systems for ESP PCB/06D, ESP PCB/15D, ESP PCB/30D, ESP PCB/50D, ESP PCB/TN, ESP PCB/06E, ESP PCB/15E, ESP PCB/30E, ESP PCB/50E

Applicaton Note AN004

Protection for Local Area Networks (LAN), for ESP Cat-5, ESP Cat-5e, ESP Cat-5/Gigabit, ESP Cat-5e/Gigabit & ESP Cat-5/PoE

Application Note AN005

Protection for global telephony equipment, for ESP TN, ESP TN/BX, ESP SL TN, ESP TNQ, ESP KT1, ESP TN/JP, ESP KT1/PTC,
ESP K10T1, ESP K10T1/PTC, ESP TN/RJ11-*/6

Application Note AN006

Protection for TV, satellite and radio systems, for Cable TV, Master Antenna TV & IRS, Satellite TV systems and Terrestrial TV & Radio protectors ESP CATV/F, ESP MATV/F, ESP SMATV/F, ESP TV/EURO, ESP TV/F

Application Note AN010

Analogue and digital telecommunications protection

Application Note AN013

Protection for data and signal lines in Intrinsically Safe circuits, for data and signal line protectors ESP SL15X and ESP SL30X

For further information on our range of Application Notes or to request a copy, please contact our
Technical Department on 0115 964 3867 or CLICK HERE to complete our online enquiry form.
